Be of glass fiber reinforced polyester;
The materials used can be self-extinguishing at 960 ° C and resistant to heat above 125 ° C and ultra violet rays.
It is equipped with a window transparent for meter reading.
The mechanical protection index to be associated with IK10.
Protection: high degree of protection IP54.
Meter fixing: Presence of a device for fixing three-phase meter&the circuit breaker.
Installation mode : Wall or pole mounting.
ITEMS | PARAMETERS |
Material | Glass fiber reinforced polyester |
On / off | A triangle sealable |
Input/output | With cable gland, 2 inputs / outputs 70 mm2 sections |
Capacity | 1 three phase meter+1 MCB |
Degree of protection | IP54 |
Accessoires | For fixing energy meters and modular distribution block. |
Fixing system | 3 bosses for 1 meter box |
Suitable for | 50Hz or 60Hz |
Nominal voltage | 120V, 220V, 230V, 380V, 690V |
Nominal current | For 10A~225A power supply system, for single-phase electric energy and power measurement and control management of electric energy |
Ambient temperature | -25℃~+50℃ |
Average temperature | within 24 hours does not exceed ±35℃ |
Relative humidity | not exceed 80% at 40°C, and the lower temperature allows higher relative humidity; |
